Dosing system for liquid / self-flowing components
NODOPUR series
If the customer specs for the compact MDM series can no longer be fulfilled, or the desired equipment exceeds the existing capabilities, the NODOPUR Series can be deployed.
The basic model is mounted on a mobile frame with integrated sump tray and is equipped with 40, 60 or 100 l containers. Of course, all other container sizes can also be considered.
The NODOPUR can be manufactured as a 1-component dosing station, but can also be built as a mixing unit with up to 8 components. The system is controlled via a Siemens touch panel on which the PLC programming is visualized. Our internal programming department designs the function and operation of each machine according to customer requirements or optimizes it for the individual process.
In volume flow-controlled systems, the mixing ratio is regulated in the control system in very short cycle times. In systems without volume flow control, the drives also receive their setpoint speeds from the PLC after the system has been calibrated.
Information about possible components and configurations can be obtained from our sales team.
Basic equipment
- Suitable for liquid synthetic resins of polyurethane, epoxy and silicone
- Flow rates can be specified within 0.1 to 100 l/min
- Adjustable mixing ratio (self-regulating on request)
- Static mixer or disposable rotary plastic mixer possible
- Stainless steel container 3 l to 100 l
- Control: from simple user interface to touch panel
- Different tube lengths
- Requires compressed air
- Power connection: 400 volts
- Stationary or mobile, powder-coated steel frame (free choice of color) with integrated drip tray
Technical Data
| Components | 1C or more components |
| Viscosity range | 1 – 60,000 mPas |
| Mixing ratio | Adjustable mixing ratio (self-regulating on request) |
| Flow rate | Can be specified in the range from 0.1 to 100 l/min |
| Control system | From simple user interface to touch panel |
| Container | various container sizes available from 3 l |
| Available modules |
|
Module elements
A dosing system of the NODOPUR series can be equipped with the following modules. As a manufacturer of special machines we adapt all machines to the respective process conditions.
Material Degassing
- Quality-impairing air and humidity are removed from the resin
- Improved manufacturing process
- Enhanced product quality
Process-integrated evacuation of air and moisture from synthetic resins and hardeners before dosing and mixing with the T-EVAC degassing station.
With this module you can significantly improve your forming processes as well as your product quality. The new degassing station is suitable for both epoxy resin and polyurethane resin degassing.
The system solution is designed in two variants: First, as an offline degassing at a central location where several dosing units can be filled with degassed material. Second, as an inline degassing directly integrated into the dosing system and adapted to the process requirements.
Measurably better results with degassed material
Material test: Optimal result with degassed resin and hardener
Test result without degassing: visible air inclusions (light discoloration)
| Categories : |
Liquid components
|
|---|
Heated tanks
Heating hose (black) connected to the mixing head
Heating of the individual components
Heated 60 l tank with agitator
Cold spot heating
Heating
All machine parts, from the container to the hose and mixing head, can be heated to reduce the viscosity of the material – for example, to shorten the pot life or improve mixing of the components. Depending on the application, there are several options available.
Container
- Jacket heating (adapted to the container)
- Double jacket (heating with water or oil)
- Extra agitators for a better heat distribution
Hoses
- Heated hoses
- Insulation
Depending on the sensitivity of the material, all possible cold spots must be additionally heated or insulated. Heating cartridges, ring heaters and heating tarpaulins are used in this process.
| Categories : |
Liquid components, pastöse Komponenten
|
|---|
Mobility
It may be necessary for a plant to be mobile, depending on its size and location/purpose. There are several ways to achieve mobility:
- Mobile frame
- Own drive unit
- Trailer coupling
| Categories : |
Liquid components, pastöse Komponenten
|
|---|
Volume Flow Control
Machines with a volume flow control system continuously measure the flow rate of the material and report any deviations to the pumps, which automatically adjust the flow rate accordingly. This happens within seconds and guarantees a constant flow rate and mixing ratio.
| Categories : |
Liquid components, pastöse Komponenten
|
|---|
Refill
To keep the dosing process running longer, we offer refills from IBCs or drums. There are different solutions for the realization of a refill.
Automatic Refill
- 1st option: Dosing containers are connected to a mobile refilling station (modern connection with couplings without loss of material)
- 2nd option: Dosing containers are connected directly on the base frame with e.g. an IBC
- 3rd option: Refill containers are also located on the base frame
The process is controlled via automatic refilling e.g. when a minimum sensor level is reached.
Vacuum Refill
If the material must not come into contact with air, we offer dosing containers in vacuum atmosphere. When refilling, the negative pressure is used to “pull” the material out of the refill containers.
Free Refill
The free refill, also called “free-flow”, uses gravimetry. The material flows from the higher positioned refill container into the dosing containers. No pump is required.
| Categories : |
Liquid components, pastöse Komponenten
|
|---|
Sample projects / Already built systems
Full automation sets new standards in encapsulation
TARTLER GROUP implements an integrated system solution for cutting-edge encapsulation technology For increased productivity and efficient production of large quantities, [...]
Innovative vacuum technology for composite users
TARTLER presents its new system solution for direct infusion for the first time at JEC 2022 JEC World at the [...]
Evacuated resin matrix as key factor
TARTLER supplies dosing-mixing systems including vacuum degassing for pultrusion Pultrusion is regarded as the standard technology for the automated production [...]
Data sheet
Download more information about the NODOPUR series here.
